Exploded view
Exploded view 14: Hydraulic drive transmission ratio (P_C_ET_24_WEL_FR-HY)
Exploded view 14: Hydraulic drive transmission ratio
Model: MU-C FR-HY 100 - 160
As of series: 2024
Edition: 2026-02
Order code: P_C_ET_24_WEL_FR-HY
| Position | Order code Article no. |
Artikel | Working width | ID No. | GPSR-Info | Quantity | ||
|---|---|---|---|---|---|---|---|---|
| 1-35 |
MU0501111 00044003 |
Belt pulley | 120-160 | (00003538, 00044003, MU0501111) | find it here | 1 | Details | |
| 1-40 |
MU0501111 00044003 |
Belt pulley | 120-160 | (00003538, 00044003, MU0501111) | find it here | 1 | Details | |
| 1-45 |
MU0501111 00044003 |
Belt pulley | 120-160 | (00003538, 00044003, MU0501111) | find it here | 1 | Details | |
| 1-55 |
MU0501111 00044003 |
Belt pulley | 120-160 | (00003538, 00044003, MU0501111) | find it here | 1 | Details | |
| 2 |
00001087 00001087 |
Belt pulley | 120-160 | (00001087, 00002360, MU0501101) | find it here | 1 | Details | |
| 3-35 |
00008140 00008140 |
Clamping bush | 120-160 | (00008140, TL201222) | find it here | 1 | Details | |
| 3-40 |
00008140 00008140 |
Clamping bush | 120-160 | (00008140, TL201222) | find it here | 1 | Details | |
| 3-45 |
00008140 00008140 |
Clamping bush | 120-160 | (00008140, TL201222) | find it here | 1 | Details | |
| 3-50 |
MU6800316 00044041 |
Clamping bush | 120-160 | (00044041, MU6800316, TL161022) | find it here | 1 | Details | |
| 3-55 |
00008140 00008140 |
Clamping bush | 120-160 | (00008140, TL201222) | find it here | 1 | Details | |
| 3-60 |
00008140 00008140 |
Clamping bush | 120-160 | (00008140, TL201222) | find it here | 1 | Details | |
| 4 |
MU981805 00044042 |
Clamping bush | 120-160 | (00044042, MU981805) | find it here | 2 | Details | |
| 5-35 |
MU0501995 00010864 |
V-belt | 120-160 | (00010864, MU0501995) | find it here | 2 | Details | |
| 5-40 |
MU0501995 00010864 |
V-belt | 120-160 | (00010864, MU0501995) | find it here | 2 | Details | |
| 5-45 |
MU0501995 00010864 |
V-belt | 120-160 | (00010864, MU0501995) | find it here | 2 | Details | |
| 5-55 |
MU0501995 00010864 |
V-belt | 120-160 | (00010864, MU0501995) | find it here | 2 | Details | |
| 5-60 |
MU0501995 00010864 |
V-belt | 120-160 | (00010864, MU0501995) | find it here | 2 | Details |
